Clutch Kit with Bearings

Specifications

Loose Disc Material: Organic
Captive Disc Material: Organic
Cover Size: 310/310mm
Cover Type: Dual Cover

Barcode 128

S.131125

Barcode EAN13

5045161311256

Brand

LUK

Captive Disc Material

Organic

Contains

Dual Cover - 231005111 Loose Disc - 331008716 Flywheel Bearing - 410013340 Transmission Bearing - 500005910 PTO Bearing - 500005810

Cover Size (mm)

310/310

Cover Type

Dual Cover

Cushion

with segment cushion

Damper

with compensating springs

Dual Cover Control

Independent

Housing Type

Cast Iron

Loose Disc Material

Organic

Loose Disc Size (mm)

310

Loose Disc Spline ID (mm)

26.7

Loose Disc Spline OD (mm)

30

Loose Disc Spline Quantity

16

Loose Disc Type

Torsion Sprung

Number of Bolts

12

Number of Levers

6

Tariff Code

8483308090

Technical Specifications

Cover Size: 310/310mm
Contains: Dual Cover - 231005111 Loose Disc - 331008716 Flywheel Bearing - 410013340 Transmission Bearing - 500005910 PTO Bearing - 500005810

Suitable For Make/Model

Renault

103-12, 103-14, 103-52, 103-54, 106-14, 781, 781S, 95-12, 95-12TS, 95-12TX, 95-14TS, 95-14TX, 951, 951-4, 981-4

Oem Part Numbers

Claas

0011309700, 0011309700?, 11309700

L.U.K.

631138911, 631 1389 11, 6311389110, 631 1389 110
