ECE Rating: Reg 10 CE Approved: Yes IP Rating: IP6K9K Connection Type: DJ7028C-1.5-11 Connector
Sparex
Alternative to
Work Light Oval 12V RH & LHS.22391https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/22391_pic1.jpgSparexOverall height 160mm Overall length 140mm Overall width 95mm IP Rating Connection Type: ConnectorS.22391
Barcode 128
S.151852
Barcode EAN13
5045161518525
Beam Angle
140°
Beam Type
Flood Beam
Brand
Sparex
Cable length (mm)
400
California Proposition 65 Warning
WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
CE Approved
Yes
Connection Type
DJ7028C-1.5-11 Connector
ECE Rating
Reg 10
Effective Lumens
2400
Fixing:
Bracket
Housing Material
Aluminium
Interference EMC EMI CISPR 25 Description
Class 5: No electromagnetic interference
Interference EMC EMI CISPR 25
Class 5
IP Rating
IP6K9K
Lens Colour
Clear
Lens Material
Plastic Safety Glass
Lighting Series
Tractor Fit
Light source
LED
Lumens Raw
4500
Lux Value
8275
Number of LEDs:
15 LEDs
Overall height (ins)
4-29/64
Overall height (mm)
113
Overall length (ins)
6-11/32
Overall length (mm)
161.2
Overall width (ins)
3-1/32
Overall width (mm)
76.8
Power Consumption @ 12V:
3.3Amps
Power Consumption @ 24V:
1.67Amps
Related products
Superseal Block Connector-2 Way Kit (1pc male / 1pc female) AgripakS.792374https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/792374_pic1.jpgSparexLED Work Light, Interference: Class 3, 4500 Lumens Raw, 10-30VS.151851https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/151851_pic1.jpgSparexECE Rating: Reg 10 CE Approved: Yes IP Rating: IP6K9K Connection Type: DJ70215-6.3-12 ConnectorLED Work Light, Interference: Class 5, 4500 Lumens Raw, 10-30VS.151855https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/151855_pic1.jpgSparexECE Rating: Reg 10 CE Approved: Yes IP Rating: IP6K9K Connection Type: DJ70215-6.3-12 ConnectorLED Work Light Kit, Lumens Raw 3600, 10-30VS.163751https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/163751_pic1.jpgSparexInterference Class 3 Overall height 109.26mm Overall length 117.9mm Cable length 100mm Beam Angle 50° IP Rating IP6K9K ECE Rating Reg 10 - E4 10R05/01*3681*00 H9 ConnectorLED Head Light Kit, Interference: Class 3, RH & LH (LH Dip), 1320 / 4050 Lumens Raw, 10-30VS.163752https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/163752_pic1.jpgSparexOffer tractor lighting upgrades with our LED Head Light Kit. These lights can be seamlessly installed, plus provide whole host of benefits that will transform any suitable machine. Benefits: Easy Installation: No need for complicated wiring modifications, simply remove your old halogen units and replace them with the new LED units. Enhanced Visibility: LED headlights provide a brighter, more focused beam, improving night-time visibility and overall road safety. Energy Efficiency: Consumes less power than traditional halogen bulbs, reducing strain on your machine’s electrical system and extending battery life. Durability: Built to withstand harsh weather conditions, ensuring reliable performance in the toughest conditions. ECE Rating: Reg 112 - E4 112R01/08*27641*00, Reg 112 - E4 112R01/08*0627*00, Reg 10 - E4 10R05/01*3681*00, Reg 10 - E4 10R05/01*4295*00 CE Approved: Yes IP Rating: IP6K9K Connection Type: 9006 ConnectorLED Work Light, Interference: Class 5, 4500 Lumens Raw, 10-30VS.163905https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/163905_pic1.jpgSparexECE Rating: Reg 10 - E4 10R05/01*4539*00 CE Approved: Yes IP Rating: IP6K9K Connection Type: DJ70215-6.3-11 ConnectorLED Work Light, Interference: Class 5, 4500 Lumens Raw, 10-30VS.163906https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/163906_pic1.jpgSparexECE Rating: Reg 10 - E4 10R05/01*4539*00 CE Approved: Yes IP Rating: IP6K9K Connection Type: 2 pcs. DJ70215-6.3-11 ConnectorS.792374, S.151851, S.151855, S.163751, S.163752, S.163905, S.163906
RoHS Approved
Yes
SAE Approved
No
Shape
Oval
Tariff Code
8539100090
Volts
10-30V
With Noise Suppression
Yes
Working Temperature °C
-40°C to 50°C
Comparison Table
Suitable For Make/Model
Suitable For Make/Model
This product is not associated with any particular make or model
OEM Part Numbers
Oem Part Numbers
This product is not associated with any particular OEM part number
Catalogue Pages
Catalogue Pages
This product does not appear in any Sparex printed catalogues
