Piston Length: 103.10mm
Compression Height: 57.35mm
Bore Ø: 102mm
Chamber Depth: 21.20mm
Chamber Ø: 54.45mm
Pin Ø: 30.17mm
No. of Rings: 3 View Product Specifications
View Suitable For
View OEM Part Numbers
Product Specifications
Specifications
Piston Length: 103.10mm
Compression Height: 57.35mm
Bore Ø: 102mm
Chamber Depth: 21.20mm
Chamber Ø: 54.45mm
Pin Ø: 30.17mm
No. of Rings: 3
Bore Ø (mm) | 102 || Piston Length (mm) | 103.10 || Chamber Depth (mm) | 21.20 || Number of Rings | 3 || Pin Ø (mm) | 30.17 || Related products | 37968 || Barcode EAN13 | 5023495596792 || Chamber Ø (mm) | 54.45 || Compression Height (mm) | 57.35 || Tariff Code | 8409990090 || Ring Type | Al Fin Ring || Crown Type | Dish Top || Chamber Type | E3 || Barcode 128 | S.59679 || Size | Standard || Returnable Product | This item can be returned || Al Fin Ring Groove | Yes
Barcode EAN13
5023495596792
Compression Height (mm)
57.35
Piston Length (mm)
103.10
Related products
LinerS.37968https://22df4504011deb964a17-39bee0485bf754a0e77a8d4deb668d89.ssl.cf4.rackcdn.com/imagelibrary_sml/37968_pic1.jpgSparexLiner - 101.98mm Bore - 196.86mm HeightS.37968
Suitable For Make/Model
Suitable For Make/Model
John Deere
1020,
1030,
1120,
1130,
1520,
1530,
1830,
2030,
2120,
2520,
3030,
3120,
3130,
4030,
830,
930
OEM Part Numbers
Oem Part Numbers
John Deere
T30015, AR55984
